Continuous Ball Mill
Product Details:
Product Description
We are a quality centric manufacturer, exporter and supplier of Continue Ball Mill, which is primarily used for the milling and mixing of different materials. It comes in tow different types that are dry mills and wet mills. Our mill is an important device for the grinding of crushed components that are primarily utilized in glass ceramics and ore dressing industries like ferrous metal, chemical fertilizers, building materials, refractory and non ferrous metals. The offered Continue Ball Mill is also known as ceramic ball mill and its structure is separated into freestanding and integral type.
Features:
- Safe to operate
- Reliable performance
- Minimum power consumption
- Cost effective
Technical Specification
|
|
|
| RPM | Material | input size | output size | Capacity | Power |
|---|---|---|---|---|---|---|---|---|
| S.N. | Model | Size | (r/min) | loading(t) | (mm) | (mm) | (T/H) | HP |
| 1 | TECBM-11 | 900x2100 | 36 | 1.4 | 15 | 0.078 | 0.5-2 | 15 |
| 2 | TECBM-12 | 900x2400 | 36 | 1.6 | 15 | 0.078 | 0.7-2.8 | 18.5 |
| 3 | TECBM-13 | 900x3000 | 36 | 2.2 | 15 | 0.078 | 0.8-3.5 | 22 |
| 4 | TECBM-14 | 1200x2400 | 30 | 3.5 | 20 | 0.078 | 0.9-4.8 | 30 |
| 5 | TECBM-15 | 1200x2800 | 30 | 3.8 | 20 | 0.078 | 1.0-5.0 | 30 |
